3M Ultra 800 Security Window Film

3M Ultra S800 Security Window Film


Ultra 800 - Safety & Security

Micro-layered, tear-resistant film for enhancedMicro-layered, tear-resistant film for enhancedprotection of people, property and possessions

Mitigates hazards from shattered glass due toMitigates hazards from shattered glass due tonatural disasters

Helps protect people from flying glass shards, oneHelps protect people from flying glass shards, oneof the most common causes of blast related injuriesand fatalities

Increases security and helps provide addedIncreases security and helps provide addedprotection against smash and grab burglaries

Increases personal safety by minimizing flying glass

Reduces fading from UV light. Furniture and fabrics have a longer acceptable life

3M Ultra S800 – Maximum Life Safety Protection

Ultra S800 is a patented micro-layered laminate which provides the maximum available tear-resistance of any film on the market. Recognizing the special technical requirements relating to blast mitigation, 3M developed micro-layer ULTRA series window security laminates. S800 is the best solution to mitigate a potential blast situation. When this film is applied, it makes it very difficult to enlarge a hole in a door or window and gain access to a building or home.

Light transmission values on various glass substrates

Single Pane Window87%
Single Pane, Tinted Window52%
Insulated Window77%
Insulated & Tinted Window 46%


Ultra S800 is a clear 8 mil (0.22mm) security film that can also be used to combat and deter smash and grab crime. Optimal resistance is achieved when this laminate is used in conjunction with 3M's Impact Protection Attachment System. 3M Ultra S800 has set the standard for blast mitigation in Canada by providing maximum life safety.

bomb blast

Bomb Blast Mitigation

> Help protect people from flying glass shards, one of the most common causes of blast related injuries and fatalities.

Completed Testing
• ASTM F1642
• GSA TS01-2003
• ISO 16933
personal safety

Safety Glazing

> Upgrade your glass to meet safety glazing codes and keep occupants safe.

Completed Testing

• ANSI Z97.1
• 16 CFR CPSC 1201
• EN 12600

break and enter

Crimes & Forced Entry

> Provides precious time by helping to deter unwanted individuals from entering your building or home.

Completed Testing
Independent lab evaluations,
contact 3M for details

seismic mitigation

Seismic Glass Breakage

> Help keep glass fragments from falling from your windows, helping to protect people and property.

Completed Testing
• ANSI Z97.1
• 16 CFR CPSC 1201

Film Properties (nominal)

Film Type Film Thickness Construction Tear Resistance Tensile Strength
Ultra 800 8 mil (0.20mm) Micro-layered 1,200 lbs% 32,000 psi
(220 MPa)
Film Type Break Strength Elongation at Break Peel Strength Abrasion Resistance
Ultra 800 255 lbs/in (1,134 N / 25mm) 130% > 6 lbs/in (27 N / 25mm) <3%
